PreSonus Eris Studio 5 Monitor Speaker (Single)

PreSonus Eris Studio 5 — Precision Monitoring for Professional Studios

The PreSonus Eris Studio 5 is a professional-grade studio monitor designed to deliver accurate sound reproduction in both home and professional studio environments. With its advanced features and robust construction, it caters to audio engineers, producers, and musicians seeking reliable monitoring solutions

Exceptional Sound Clarity

The Eris Studio 5 features a 5.25-inch woven composite low-frequency driver and a 1-inch ultra-low mass silk-dome tweeter, delivering a transparent and detailed response across the full frequency spectrum. Ideal for mixing, mastering, and critical listening, it captures subtle dynamics with precision.

Wide Dispersion and Balanced Imaging

Thanks to the Elliptical Boundary Modeled (EBM) waveguide, the Studio 5 maintains a wide horizontal (120°) and focused vertical (60°) dispersion, offering a generous sweet spot while minimising acoustic reflections from desk and ceiling surfaces.

Robust Amplification and Acoustic Tuning

Powered by an 80W Class AB bi-amplification system (45W LF, 35W HF), the Eris Studio 5 delivers up to 102 dB SPL. It includes acoustic tuning controls such as Acoustic Space settings (Flat, -2 dB, -4 dB), High and Mid-frequency adjustments (±6 dB), and a Low Cut filter (Flat, 80 Hz, 100 Hz) to tailor the sound to your room's acoustics.

Reliable, High-Headroom Amplification

Equipped with a 45W LF and 35W HF Class AB bi-amplification system, the Eris Studio 5 produces up to 102 dB SPL, ensuring sufficient volume and headroom for close-field or midfield monitoring without distortion.

Durable and Stylish Design

Housed in a vinyl-laminated, medium-density fiberboard (MDF) enclosure with a front-firing acoustic port, the Eris Studio 5 is built for durability and enhanced bass response. Its sleek appearance complements any studio setup.

KEY FEATURES: PreSonus Eris Studio 5 Monitor Speaker (Single)

• Precision Sound – 5.25" woven composite woofer and 1" silk-dome tweeter for accurate frequency response.
• Wide EBM Waveguide – 120° x 60° dispersion pattern for an expansive sweet spot and stable imaging.
• Flexible Acoustic Tuning – Includes mid/high frequency trim, Acoustic Space controls, and low-cut filter.
• Powerful Output – 80W total Class AB amplification (45W LF, 35W HF) with a max SPL of 102 dB.
• Multiple Inputs – XLR, TRS, and RCA connections to suit professional and consumer gear.
• Durable Construction – Vinyl-laminated MDF enclosure with front-firing bass port for focused low end.
