Wharfedale Pro Titan AX15 15" Active PA Speaker With DSP (Black)

Powerful, High-Output PA Speaker With Built-in DSP – Wharfedale Titan AX15.

The Wharfedale Titan AX15 is a versatile 15” active PA speaker designed for live sound, mobile DJs, schools, houses of worship, and small to medium performance venues. With a peak output of 840W and 129dB maximum SPL, it offers impressive headroom and clarity for both speech and music reproduction.

Its lightweight yet rugged polypropylene cabinet makes it easy to transport and set up, while the integral mixer with mic/line switching ensures plug-and-play operation. Whether used as a main PA, floor monitor, or in an array, the AX15 delivers consistent, reliable performance in demanding environments.

Advanced DSP For Flexible Sound Control

Equipped with a 6-position DSP, the Titan AX15 allows you to instantly adapt its sound for different applications. Choose between Flat, Monitor, Speech, Bass, Punch, or Live modes to suit your setup. The onboard DSP also features a hi-pass filter, driver protection, and clip limiting to safeguard your system during high-output use.

Built For Touring And Installation

Constructed from injection-moulded polypropylene with a robust steel grille, the AX15 is designed to handle the rigours of portable PA work. It features 10 M8 rigging points for flown installation, rubber-padded handles for easy lifting, and a 35mm pole socket with locking screw for stand mounting. Its trapezoid design makes it ideal for use as a wedge monitor or in multi-speaker arrays.

Connectivity And Mixer Functions

The AX15 includes a built-in 2-channel mixer with switchable mic/line inputs, making it ideal for quick setups without an external mixing console. Dual XLR and 1/4” jack inputs, plus a balanced XLR link output (switchable between loop and mix), provide flexible routing options for more complex systems.

KEY FEATURES: Wharfedale Pro Titan AX15

• Bi-Amplified Class-D Power: 350W LF + 70W HF (RMS) for 420W continuous output, 840W peak.
• LF Driver: 15” woofer with 3” voice coil, moisture-resistant for outdoor and demanding environments.
• HF Driver: 1.75” titanium compression driver for detailed high-frequency reproduction.
• DSP Presets: Six user-selectable EQ settings (Flat, Monitor, Speech, Bass, Punch, Live) plus hi-pass switch.
• Max SPL: 129dB for powerful coverage in small to medium-sized venues.
• Cabinet: Rugged polypropylene shell with trapezoid design, monitor angle, and rubber-padded handles.
• Rigging & Mounting: 10 x M8 points, tripod stand adapter with locking screw, top-stacking receptacles.
• Inputs & Outputs: 2 x XLR, 2 x 1/4" jack inputs, switchable mic/line, balanced XLR loop/mix output.


Download the User Manual Here
